OJL280A BLACK IN 1XAL/CU120 DISTRIBUTION BLOCK
The OJL280A distribution block from MOREK is the ideal solution for efficiently splitting large cross-section wires into smaller ones.
Application
The OJL distribution blocks from MOREK are designed for splitting larger cross-section wires into several smaller ones. They come in various versions that can be used in different construction and industrial applications.
Technical Data
- Nominal connection cross-section: 120 mm² Al/Cu
- Ability to connect flexible busbars MOFLEX 10 x 25 mm or several bars 1 x 25 mm
- Mounting on standard DIN rail or on a solid surface
- Operating temperature: up to 80°C
- Enclosure protection degree: IP20
- Rated voltage: up to 1000V AC/DC
- Material: tinned aluminum, polyamide PA66
- Certification: compliance with standards EN 61238-1 and EN 60947-7-1
