Combined Switch K60 DPNVigiK-B20-30-AC B 20A
The combined switch DPNVigiK-B20-30-AC B 20A 1N-pole 30 mA type AC, with catalog number A9D22620, is an extremely functional device that enhances electrical safety in installations.
Application
The switch is ideal for use in both residential and industrial electrical installations, protecting against the effects of overloads and short circuits. The two-part lever indicates which part of the switch has tripped, facilitating diagnostics.
Technical Data
- Type: DPNVigiK-B20-30-AC
- Rated current: 20A
- Number of poles: 1N
- Sensitivity: 30 mA
- Catalog number: A9D22620
- Visi-Trip indicator: white-red
- Visi-Safe indicator: green
- Functionality testing: test button
