OJL280A Blue Distribution Block
The OJL280A distribution block from MOREK is an advanced solution designed for splitting larger gauge wires into several smaller ones, ensuring high quality and reliability.
Application
The OJL distribution blocks are designed for connecting both flexible MOFLEX busbars and several standard-sized busbars. They are ideal for electrical installations requiring effective wire management.
Technical Data
- Type: OJL280A
- Material: tinned aluminum, polyamide PA66
- Connection cross-section: 120 mm² Al/Cu
- Maximum voltage: 1000V AC/DC
- Class: A (compliance with EN 61238-1 and EN 60947-7-1 standards)
- Operating temperature: up to 80°C
- Protection degree: IP20
- Mounting: on DIN rail or solid flat surface
