KZS-2M C 10A/30MA/AC Residual Current Circuit Breaker
The KZS-2M C 10A 30MA AC 10KA residual current circuit breaker is a reliable device designed to protect against electric shock and to safeguard electrical installations from fires and damage.
Application
Residual current circuit breakers with overcurrent protection are used in various electrical networks (TN-S, TN-C-S, TT, IT). They provide protection against hazards arising from short circuits and overloads, making them ideal for both domestic and industrial use.
Technical Data
- Catalog number: 002173122
- Article symbol: KZS-2M AC C10/0.03
- Class name: Residual current circuit breaker with overcurrent protection
- Rated residual current: 30mA
- Rated current: 10A
- Type: AC
- Tripping characteristic: C
- Short-circuit current: 10kA
- Rated AC voltage: 240V
- Rated frequency: 50/60Hz
- Tripping time: instantaneous
- Ambient temperature: -25 to 40°C
- Number of poles: 2
- Number of modules: 2
- Wire connection capacity: 1 to 25mm²
- Neutral pole side: right
- IP protection rating: IP20
- Function: RCBO (residual current circuit breaker with overcurrent protection)
