ETIMAT 6 Circuit Breaker C 63A 3P 3M 6KA
The ETIMAT 6 circuit breaker is a reliable protection for electrical installations, ideal for homes, public buildings, and industrial facilities. It guarantees protection against short circuits and overloads.
Application
ETIMAT 6 circuit breakers are used as protection for electrical installations in various facilities, providing reliable protection against short circuits and overloads. They operate on the principle of automatic disconnection of the circuit in case of excessive current detection, which increases the safety of using electrical installations.
Technical Data
- Catalog number: 002145522
- Article symbol: ETIMAT 6 3p C63
- Class name: Circuit breaker
- Rated current [A]: 63
- Tripping characteristic: C
- Number of poles: 3
- Short-circuit current [kA]: 6
- Rated voltage AC [V]: 230/400
- Rated voltage DC [V]: 60
- Rated frequency [Hz]: 50/60
- Voltage Uimp [kV]: 6
- Degree of protection IP: IP20
- Ambient temperature [˚C]: -25 to +55
- Wire connection [mm2]: 1 – 25
- Mounting position: any
- Standards: IEC/EN 60898-1, IEC 60947-2
- Function: MCB
